F-Series Plus Cylinders
11/09
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
Dimensions in inches
Bore
Code
A
Ba*
Bb*
(FP)
(FPD)
C
DD
D
E Thread
G depth F
H
J
K
L
9/16"
(056)
1.12
0.56
0.69
0.88
2
#4
8-32 UNC
.46
.25
.22
.34
.14
10-32 UNF
3/4"
(075)
1.50
0.56
0.69
1.22
4
#6
10-32 UNC
.46
.31
.25
.34
.14
10-32 UNF
1-1/16"
(106)
2.00
0.88
0.94
1.69
4
#6
5/16-24 UNF
.70
.50
.44
.50
.25
1/8 NPT
1-1/2"
(150)
2.62
0.88
1.00
2.19
4
#10
3/8-24 UNF
.70
.63
.50
.50
.25
1/8 NPT
2"
(200)
3.12
0.95
1.06
2.69
4
#10
1/2-20 UNF
.70
.75
.63
.53
.25
1/8 NPT
2-1/2"
(250)
3.75
1.19
1.31
3.25
4
1/4
1/2-20 UNF
.70
.75
.63
.66
.33
1/4 NPT
3"
(300)
4.25
1.25
1.38
3.78
4
1/4
5/8-18 UNF
.73
.88
.75
.69
.33
1/4 NPT
4"
(400)
5.50
1.56
1.69
4.94
4
5/16
3/4-16 UNF
.80
1.00
.88
.84
.42
3/8 NPT
1
3
4
2
DD number of
clearance holes
for D socket head
cap screw
Port
position
E piston
rod thd
x G deep
H across
flats
K
K
L port
(2 plc)
F Rod
Dia.
A
J
J
Ba + stroke
0.13
C
bolt circle
CL
1
3
4
2
DD number of
clearance holes
for D socket head
cap screw
Port
position
E piston
rod thd
x G deep
H across
flats
K
K
L port
(2 plc)
F Rod
Dia.
A
J
J
Bb + stroke
0.13
C
bolt circle
F Rod
Dia.
0.13 + stroke
CL
FP (basic model BAM)
Double acting, single rod end
FPD (basic model BAM)
Double acting, double rod end
FP - Double acting, single rod end
FPD - Double acting, double rod end
* Length may increase with certain option combinations.
