Norgren PRA/882000/M IVAC Cleanline cylinder - Manual (Page 6)

PRA/882000/M
N/us 1.5.260.06 4/13
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
© Norgren, Inc. 2013
A-A A-A
ш 32 ... 63 ш 80 & 100
ø 80 & 100
ш 32 ... 63 ш 80 & 100
A
B
B
A
A
A
ø 32 ... 63
7
8
12 10 9
4
3 5 2
13
14
13
1
6
11
L8 + #
MM
h
9
R
L1
KW
L12
M12 x 1
(52.5)
0.45
(11.5)
1.61
(41) G2
AM WH
L2 G1
PL VD PL
G VA
BG
KK
ø B
e 11
SW
EE
0.04
(1) 0.2
(5.5)
0.08
(2)
1.22 (31)
E2
1.08 (27.5)
E
RT
BH
BH
ø BA
e 11
E4
E3
PL2
KV
PL1
X1
RT
BG
G
RT
BG
L9
RT
Dimensions
# Stroke
1 Cushion adjustment front end cover
2 Magnetically operated switches (AF 11)
3 LED - magnetically operated switches
4 Main valve
5 Pilot block
6 Output ports (2&4)
7 Air supply
8 Exhaust position, do not obstruct
9 Without function - do not use
10 LED - pilot valve
11 Manual override
12 Cover for cushion and Speed control adjustment
13 Speed control adjustment
14 Cushion adjustment rear end cover
(without cover)
Magnetically operated switches with LED M12 cables
25
Model
Reed *3) Solid state
Voltage *2)
(V a.c.) (V d.c.)
Current
max. (mA)
Temperature
°F (°C) Features
Cable
length (m)
Cable
type Data sheet
M/50/LSU/2V – 10 ... 240 10 ... 170 180 -4°F to 176°F (-20°C to 80°C) – 2 PVC 2 x 0.25 N/en 4.3.005
– M/50/EAP/2V – 10 ... 30 150 -40°F to 176°F (-40°C to 80°G) PNP 2 PVC 3 x 0.25 N/en 4.3.007
*2) Supply voltage 24 V d.c. (± 10%) max for P.A/88200/M only.
*3) For use with 32 mm bore - consult factory.
Cable
length
(m)
Plug with moulded cable
IP 67
21
Y-cable, M12 female
8 pin, 2 x M12 male 4 pin
IP67
21
2 M/P74581/2 (straight) M/P73201 (0.45 m)
5 M/P74581/5 (straight)
10 M/P74581/10 (straight)
2 M/P74582/2 (90°)
5 M/P74582/5 (90°)
10 M/P74582/10 (90°)
Mountings and service kits (cont.)
