Norgren PRA/882000/M IVAC Cleanline cylinder - Manual (Page 13)

PRA/882000/M
N/us 1.5.260.013 4/13
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
© Norgren, Inc. 2013
Narrow hinge SS
EM
K 1
K 2
ø S
ø D
L
1
ø
CN
G
7
G 2
G 3
G 1
R
CA
H
2
Ø CA Ø
CN G7
Ø
D
H2 EM G1 G2 G3 K1 K2 L1 R Ø
S
lb.
(kg)
Model
(SS)
32 1.26 0.39 0.43 0.31 0.39 0.83 0.71 1.22 1.50 2.01 0.06 0.39 0.26 0.33 M/P19931
(32) (10) (11) (8) (10) (21) (18) (31) (38) (51) (1.6) (10) (6.6) (0.15)
40 1.42 0.47 0.43 0.39 0.47 0.94 0.87 1.38 1.61 2.13 0.06 0.43 0.26 0.44 M/P19932
(36) (12) (11) (10) (12) (24) (22) (35) (41) (54) (1.6) (11) (6.6) (0.2)
50 1.77 0.63 0.59 0.47 0.63 1.30 1.18 1.77 1.97 2.56 0.06 0.51 0.35 1.06 M/P19933
(45) (16) (15) (12) (16) (33) (30) (45) (50) (65) (1.6) (13) (9) (0.48)
63 1.97 0.63 0.59 0.47 0.63 1.46 1.38 1.97 2.05 2.64 0.06 0.59 0.35 1.10 M/P19934
(50) (16) (15) (12) (16) (37) (35) (50) (52) (67) (1.6) (15) (9) (0.5)
80 2.48 0.79 0.71 0.55 0.79 1.85 1.57 2.36 2.60 3.39 0.10 0.59 0.43 1.65 M/P19935
(63) (20) (18) (14) (20) (47) (40) (60) (66) (86) (2.5) (15) (11) (0.75)
100 2.80 0.79 0.71 0.59 0.79 2.17 1.97 2.76 2.99 3.78 0.10 0.75 0.43 2.64 M/P19936
(71) (20) (18) (15) (20) (55) (50) (70) (76) (96) (2.5) (19) (11) (1.2)
Standard
Universal rear eye UR
Conforms to ISO 15552, type MP6
EN
Z
Z
FL
ER
R
CN
H
7
Ш Ш CN H7 EN ER FL R Z lb. (kg) Model (UR)
32 0.39 0.55 0.63 0.87 0.57 0.33 QA/8032/33
(10) (14) (16) (22) (14.5) 13° (0.15)
40 0.47 0.63 0.71 0.98 0.71 0.55 QA/8040/33
(12) (16) (18) (25) (18) 13° (0.25)
50 0.63 0.83 0.83 1.06 0.75 0.88 QA/8050/33
(16) (21) (21) (27) (19) 15° (0.4)
63 0.63 0.83 0.91 1.26 0.94 1.21 QA/8063/33
(16) (21) (23) (32) (24) 15° (0.55)
80 0.79 0.98 1.10 1.42 0.94 1.98 QA/8080/33
(20) (25) (28) (36) (24) 15° (0.9)
100 0.79 0.98 1.18 1.61 1.14 3.30 QA/8100/33
(20) (25) (30) (41) (29) 15° (1.5)
Corrosion protected version
32
0.39 0.55 0.63 0.87 0.57 0.33 PVQA/8032/33
(10) (14) (16) (22) (14.5) 13° (0.15)
40 0.47 0.63 0.75 0.98 0.71 0.55 PVQA/8040/33
(12) (16) (19) (25) (18) 13° (0.25)
50 0.63 0.83 0.83 1.06 0.75 0.88 PVQA/8050/33
(16) (21) (21) (27) (19) 13° (0.4)
63 0.63 0.83 0.94 1.26 0.94 1.21 PVQA/8063/33
(16) (21) (24) (32) (24) 15° (0.55)
80 0.79 0.98 1.10 1.42 0.94 1.98 PVQA/8080/33
(20) (25) (28) (36) (24) 15° (0.9)
100 0.79 0.98 1.18 1.61 1.14 3.30 PVQA/8100/33
(20) (25) (30) (41) (29) 15° (1.5)
Standard
