3-9
BIOS Setup
Serial Port 1 / 2 Address
Select an address and a corresponding interrupt for the serial port 1/2.
Serial Port2 Mode Select
This setting allows you to specify the operation mode for serial port 2.
[Normal] RS-232C Serial Port
[IrDA] IrDA-compliant Serial Infrared Port
[ASKIR] Amplitude Shift Keyed Infrared Port
Parallel Port Address
This setting specifies the I/O port address and IRQ of the onboard parallel port.
Parallel Port Mode
[Normal] Standard Parallel Port
[EPP] Enhanced Parallel Port
[ECP] Extended Capability Port
[ECP + EPP] Extended Capability Port + Enhanced Parallel
To operate the onboard parallel port as Standard Parallel Port only,
[Normal]. To operate the onboard parallel port in the EPP mode simultaneously,
choose [EPP]. By choosing [ECP], the onboard parallel port will ECP mode
only. Choosing [ECP + EPP] will allow the onboard parallel support both the
ECP and EPP modes simultaneously.
Parallel Port IRQ
This item allows you to set parallel port IRQ.
Hardware Health Configuration
