MS-9804 Mainboard
1-2
Mainboard Specifications
Pro cessor Suppo rt
- AMD Sempron ,Athlon 64/64 X2 (Dual Core) processor with AM2
package
- 4-pin CPU fan pinheader with Smart Fan Speed Control
Supported FSB
- Hyper Transport supporting speed up to 1 GHz (2000MT/s)
Chi p set
- Northbridge : AMD RS690T
- Southbridge : AMD SB600
Memo ry Sup port
- DDR2 400/533/667/800 (4GB Max)
- 2 DDR2 SO-DIMM slots (unbuffered)
LAN
- 2 PCI-E Gb LAN by Marvell 88E8056
Audio
- Realtek ALC888 7.1-channel HDA codec
- 6 watt amplifier
IDE
- 1 40-pin IDE connector
- Supports 2 IDE devices
SATA
- 2 SATA II ports by SB600
- Supports storage and data transfers at up to 300MB/s
Expansion Slots
- 1 PCI slot
- 1 Mini PCI-E socket
