2-14
MS-9804 Mainboard
Front USB Connector: JUSB1/ JUSB2
The USB 2.0 pinheader is compliant with Intel ® I/O Connectivity Design Guide. USB 2.
0 technology increases data transfer rate up to a maximum throughput of 480Mbps,
which is 40 times faster than USB 1.1, and is ideal for connecting high-speed USB
interface peripherals such as USB HDD, digital cameras, MP3 players, printers,
modems and the like.
Important
Note that the pins of VCC and GND must be connected correctly to avoid
possible damage.
Pin Description Pin Description
1 GND 2 Y_L
3 C_L 4 COMP_L
5 GND 6 Key (no pin )
JTV1 Pin Definition
TV-Out Connector: JTV1
The mainboard provides a TV-Out connector.
JTV1
CRT HDMI LVDS TV OUT
CRT X V X
HDMI X V X
LVDS V V V
TV OUT X X V
Display Matrix
V : Support X : No Support
1
3
4
PIN SIGNAL PIN SIGNAL
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 GND 8 GND
9 Key (no pin) 10 NC
Pin Definition
JUSB1/ 2
1
2 10
9
