2-7
Hardware Setup
Power Supply
ATX 20-Pin System Power Connector: ATX1
This connector allows you to connect to an ATX power supply. To connect to the ATX
power supply, make sure the plug of the power supply is inserted in the proper
orientation and the pins are aligned. Then push down the power supply firmly into the
connector.
ATX1 Pin Definition
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3 GND
4 5V
5 GND
6 5V
7 GND
8 PW_OK
9 5V_SB
10 12V
ATX1
10
1
20
11
PIN SIGNAL
1 GND
2 GND
3 12V
4 12V
Pin Definition
ATX 12V Power Connector: JPW1
This 12V power connector JPW1 is used to provide power to the CPU.
JPW1
3
4
2
1
Important
Power supply of 350watts (and above) is highly recommended for system
stability.
