Page 10
IN-ICST-01-07 10
Pick and Run Screen:
Target Inspector Screen:
Single click on a program in list brings the
program description into the description
window for review prior to loading.
Double click will auto load the program into the
board processor.
The program controls “Tweakable
parameters”associated with the program are
also shown.
This screen shows boards I/O’s ,
This screen allows operator to check
And verify the operation of the boards
I/O functions.
Use in conjunction with supplied program
900000 to check the functionality of the
of the board. This program is loaded onto
the driver when shipped.
