CS5361
6 DS467F2
ANALOG CHARACTERISTICS (CS5361-DZZ)
Test conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is
10 Hz to 20 kHz.
Parameter Symbol Min Typ Max Unit
Single Speed Mode Fs = 48 kHz
Dynamic Range A-weighted
unweighted
106
103 114
111
-
- dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
THD+N
-
-
- -105
-91
-51
-95
-
-
dB
dB
dB
Double Speed Mode Fs = 96 kHz
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
106
103
-
114
111
108
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -105
-91
-51
-102
-95
-
-
-
dB
dB
dB
dB
Quad Speed Mode Fs = 192 kHz
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
106
103
-
114
111
108
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -105
-91
-51
-102
-95
-
-
-
dB
dB
dB
dB
Dynamic Performance for All Modes
Interchannel Isolation - 110 - dB
Interchannel Phase Deviation - 0.0001 - Degree
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Gain Error -5 - 5 %
Gain Drift -100 - 100 ppm/°C
Offset Error HPF enabled
HPF disabled
-
- -
- 0
100
LSB
LSB
Analog Input Characteristics
Full-scale Input Voltage 1.07*VA 1.13*VA 1.18*VA Vpp
Input Impedance (Differential) (Note 5) 7.5 - - k
Ω
Common Mode Rejection Ratio CMRR - 82 - dB
