CS5361
4 DS467F2
1.0 CHARACTERISTICS AND SPECIFICATIONS
All Min/Max characteristics and specifications are guaranteed over the specified operating conditions. Typical per-
formance characteristics and specifications are derived from measurements taken at typical supply voltages and
T
A
= 25 °C.
SPECIFIED OPERATING CONDITIONS
GND = 0 V, all voltages with respect to GND.
ABSOLUTE MAXIMUM RATINGS
GND = 0 V, All voltages with respect to GND. (Note 1)
Notes: 1. Operation beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
2. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause SCR
latch-up.
3. The maximum over/under voltage is limited by the input current.
Parameter Symbol Min Typ Max Unit
DC Power Supplies: Positive Analog
Positive Digital
Positive Logic
VA
VD
VL
4.75
3.1
2.37
5.0
3.3
3.3 5.25
5.25
5.25 V
V
V
Ambient Operating Temperature Commercial (-KSZ/-KZZ)
Automotive (-DZZ)
T
AC
T
AA
-10
-40 -
- 70
85 °C
°C
Parameter Symbol Min Max Units
DC Power Supplies: Analog
Logic
Digital
VA
VL
VD
-0.3
-0.3
-0.3 +6.0
+6.0
+6.0 V
V
V
Input Current (Note 2) I
in
-10 +10 mA
Analog Input Voltage (Note 3) V
IN
- 0.7 VA + 0.7 V
Digital Input Voltage (Note 3) V
IND
-0.7 VL + 0.7 V
Ambient Operating Temperature (Power Applied) T
A
-50 +95
°C
Storage Temperature T
stg
-65 +150
°C
