6 DS564F2
CS5341
Confidential Draft
3/11/08
ANALOG CHARACTERISTICS - AUTOMOTIVE GRADE
Test Conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is
10 Hz to 20 kHz.
6. Referred to the typical full-scale input voltage
Dynamic Performance for Automotive Grade VA = 5 V VA = 3.3 V
Single-Speed Mode Fs = 48 kHz Symbol Min Typ Max Min Typ Max Unit
Dynamic Range A-weighted
unweighted
97
94 105
102 -
- 94
91 102
99
-
- dB
dB
Total Harmonic Distortion + Noise (Note 6)
-1 dB
-20 dB
-60 dB
THD+N
-
-
- -98
-82
-42 -90
-
-
-
-
- -95
-79
-39 -87
-
-
dB
dB
dB
Double-Speed Mode Fs = 96 kHz Symbol Min Typ Max Min Typ Max Unit
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
97
94
-
105
102
99
-
-
- 94
91
-
102
99
96
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 6)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -98
-82
-42
-95 -90
-
-
-
-
-
-
- -95
-79
-39
-87 -87
-
-
-
dB
dB
dB
dB
Quad-Speed Mode Fs = 192 kHz Symbol Min Typ Max Min Typ Max Unit
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
97
94
-
105
102
99
-
-
- 94
91
-
102
99
96
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 6)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -98
-82
-42
-95 -90
-
-
-
-
-
-
- -95
-79
-39
-87 -87
-
-
-
dB
dB
dB
dB
Dynamic Performance All Modes Min Typ Max Unit
Interchannel Isolation - 90 - dB
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Gain Error -10 - +10 %
Gain Drift -
±
100 - ppm/°C
Analog Input Characteristics
Full-Scale Input Voltage 0.50*VA 0.56*VA 0.62*VA Vpp
Input Impedance - 25 - k Ω
