DS564F2 15
CS5341
Confidential Draft
3/11/08
4. APPLICATIONS
4.1 Single-, Double-, and Quad-Speed Modes
The CS5341 can support output sample rates from 2 kHz to 200 kHz. The proper speed mode can be de-
termined by the desired output sample rate and the external MCLK/LRCK ratio, as shown in
Table 1 .
Table 1. Speed Modes and the Associated Output Sample Rates (Fs)
4.2 Operation as Either a Clock Master or Slave
The CS5341 supports operation as either a clock master or slave. As a clock master, the LRCK and SCLK
pins are outputs with the left/right and serial clocks synchronously generated on-chip. As a clock slave, the
LRCK and SCLK pins are inputs and require the left/right and serial clocks to be externally generated. The
selection of clock master or slave is made via the Mode pins as shown in
Table 2 .
Speed Mode
MCLK/LRCK
Ratio
Output Sample Rate Range (kHz)
Single-Speed Mode
512x 43 - 50
256x 2 - 50
Double-Speed Mode
256x 86 - 100
128x 4 - 100
Quad-Speed Mode
128x 172 - 200
64x* 100 - 200
* Quad-Speed Mode, 64x only available in Master Mode.
M1 (Pin 16) M0 (Pin 1) MODE
0 0 Clock Master, Single-Speed Mode
0 1 Clock Master, Double-Speed Mode
1 0 Clock Master, Quad-Speed Mode
1 1 Clock Slave, All Speed Modes
Table 2. CS5341 Mode Control
