7 Ordering Information

1. Controlling dimensions are in millimeters.

2. Dimensioning and tolerancing per ASME Y 14.5M.

3. This drawing conforms to JEDEC outline MS-012, variation VGGD-6 with exception of features D2, E2, and L,

which are per supplier designation.

4. Recommended reflow profile is per JEDEC/IPC J-STD-020.

7 Ordering Information

Check with your local Cirrus Logic representative for the availability of Automotive grade packages.

Reference: Philips Semiconductor, The I²C-Bus Specification: Version 2.1, January 2000.

8 Revision History

Product

Description

Package

Pb-Free

Grade

Temp Range

Container

Order #

CS48LV12

Ultralow Power DSP

20 BALL

WLCSP

YES

Commercial

0 °C to +70°C

Tape and Reel

CS48LV12-CWZR

24 PIN QFN

YES

Commercial

0 °C to +70°C

Tape and Reel

CS48LV12-CNZR

24 PIN QFN

YES

Automotive

–40°C to +105°C

Tape and Reel

CS48LV12-ENZR

CS48LV13

Ultralow Power DSP

20 BALL

WLCSP

YES

Commercial

0 °C to +70°C

Tape and Reel

CS48LV13-CWZR

24 PIN QFN

YES

Commercial

0 °C to +70°C

Tape and Reel

CS48LV13-CNZR

24 PIN QFN

YES

Automotive

–40°C to +105°C

Tape and Reel

CS48LV13-ENZR

Revision

Date

Changes

F1

February, 2014 Initial release.

Contacting Cirrus Logic Support

For all product questions and inquiries, contact a Cirrus Logic Sales Representative.
To find the one nearest you, go to

www.cirrus.com.
