DS1057F1

16

4.7 Switching Characteristics—RESET

4.7 Switching Characteristics—RESET

Figure 4-2. RESET Timing at Power-On

Figure 4-3. RESET Timing after Power is Stable

4.8 Switching Characteristics—CLOCK

Figure 4-4. CLOCK Timing

Parameter

Symbol

Min

Max

Unit

RESET minimum pulse width low

1

1.The rising edge of RESET must not occur before the power supplies are stable at their recommended operating values. In addition, for the

configuration pins to be read correctly, the RESET T

rstl

requirement must be met.

T

rstl

1

s

All bidirectional pins high-Z after RESET low

T

rst2z

100

ns

Configuration pins setup before RESET high

T

rstsu

50

ns

Configuration pins hold after RESET high

T

rsthld

20

ns

Parameter

Symbol

Min

Max

Unit

External clock operating frequency

F

CLOCK

3.072

38.4

MHz

CLOCK period

T

CLOCK

26

325

ns

CLOCK high time

T

CLOCKh

45% · T

CLOCK

55% · T

CLOCK

ns

CLOCK low time

T

CLOCKl

45% · T

CLOCK

55% · T

CLOCK

ns

T

rstl

T

rstsu

T

rsthld

INT

BUSY/I2C_SELECT

All supplies at

recommended
operating values.

VD,

VPLL,

VL

RESET

RESET

T

rst2z

T

rstl

T

rstsu

T

rsthld

INT

BUSY/I2C_SELECT

All Bidirectional

Pins

t

CLOCKh

T

CLOCK

CLOCK

t

CLOCKl
