Cirrus Logic CS44600 User Manual
Page 46
46
DS63
3F1
CS44600
21h
Chnl A3 Comp.
Filter - Fine Adj
RESERVED
RESERVED
CHA3_FINE5
CHA3_FINE4
CHA3_FINE3
CHA3_FINE2
CHA3_FINE1
CHA3_FINE0
default
0
0
0
0
0
0
0
0
22h
Chnl B3 Comp.
Filter - Coarse Adj
RESERVED
RESERVED
CHB3_CORS5
CHB3_CORS4
CHB3_CORS3
CHB3_CORS2
CHB3_CORS1
CHB3_CORS0
default
0
0
0
0
0
0
0
0
23h
Chnl B3 Comp.
Filter - Fine Adj
RESERVED
RESERVED
CHB3_FINE5
CHB3_FINE4
CHB3_FINE3
CHB3_FINE2
CHB3_FINE1
CHB3_FINE0
default
0
0
0
0
0
0
0
0
24h
Reserved
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
default
0
0
0
0
0
0
0
0
25h
Reserved
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
default
0
0
0
0
0
0
0
0
26h
Reserved
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
default
0
0
0
0
0
0
0
0
27h
Reserved
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
default
0
0
0
0
0
0
0
0
28h
Interrupt Mode
Control
INT1
INT0
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
OVFL_L/E
default
0
0
0
0
0
0
0
0
29h
Interrupt Mask
M_SRC_UNLOCK
M_SRC_LOCK
M_RMPUP_DONE
M_RMPDN_DONE
M_MUTE_DONE
M_OVFL_INT
RESERVED
RESERVED
default
0
0
0
0
0
0
0
0
2Ah
Interrupt Status
SRC_UNLOCK
SRC_LOCK
RMPUP_DONE
RMPDN_DONE
MUTE_DONE
OVFL_INT
GPIO_INT
RESERVED
default
0
0
0
0
0
0
0
0
2Bh
Chnl Over Flow Sta-
tus
RESERVED
RESERVED
CHB3_OVFL
CHA3_OVFL
CHB2_OVFL
CHA2_OVFL
CHB1_OVFL
CHA1_OVFL
default
0
0
0
0
0
0
0
0
2Ch
GPIO Pin I/O
RESERVED
GPIO6_I/O
GPIO5_I/O
GPIO4_I/O
GPIO3_I/O
GPIO2_I/O
GPIO1_I/O
GPIO0_I/O
default
0
0
0
0
0
0
0
0
2Dh
GPIO Pin Polar-
ity/Type
RESERVED
GPIO6_P/T
GPIO5_P/T
GPIO4_P/T
GPIO3_P/T
GPIO2_P/T
GPIO1_P/T
GPIO0_P/T
default
0
1
1
1
1
1
1
1
2Eh
GPIO Pin Level/Edge
trigger
RESERVED
GPIO6_L/E
GPIO5_L/E
GPIO4_L/E
GPIO3_L/E
GPIO2_L/E
GPIO1_L/E
GPIO0_L/E
default
0
0
0
0
0
0
0
0
2Fh
GPIO Pin Status
RESERVED
GPIO6_STATUS
GPIO5_STATUS
GPIO4_STATUS
GPIO3_STATUS
GPIO2_STATUS
GPIO1_STATUS
GPIO0_STATUS
default
X
X
X
X
X
X
X
X
30h
GPIO Interrupt Mask
RESERVED
RESERVED
RESERVED
RESERVED
M_GPIO3
M_GPIO2
M_GPIO1
M_GPIO0
default
0
0
0
0
0
0
0
0
31h
PWM Config
OSRATE
RESERVED
RESERVED
A1/B1_OUT_CNFG A2/B2_OUT_CNFG
A3_OUT_CNFG
B3_OUT_CNFG
RESERVED
default
0
0
0
0
0
0
0
0
Addr
Function
7
6
5
4
3
2
1
0
