Page 23
DS723F1
23
CS43L21
4.2
Hardware Mode
A limited feature-set is available when the D/A powers up in Hardware Mode (see
Up Sequence” section on page 31
) and may be controlled via stand-alone control pins.
shows a list
of functions/features, the default configuration and the associated stand-alone control available.
Hardware Mode Feature/Function Summary
Feature/Function
Default Configuration
Stand-Alone Control
Note
Power Control
Device
DACx
Powered Up
Powered Up
-
-
Auto-Detect
Enabled
-
-
Speed Mode
Serial Port Slave
Serial Port Master
Auto-Detect Speed Mode
Single-Speed Mode
-
-
MCLK Divide
(Selectable)
“MCLKDIV2” pin 2
see Section
Serial Port Master / Slave Selection
(Selectable)
“M/S” pin 29
see Section
Interface Control
DAC
(Selectable)
“I²S/LJ” pin 3
see Section
DAC Volume & Gain
HP Gain
AOUTx Volume
Invert
Soft Ramp
Zero Cross
G = 0.6047
0 dB
Disabled
Enabled
Disabled
-
-
DAC De-Emphasis
(Selectable)
“DEM” pin 4
Signal Processing Engine (SPE)
Mix
Beep
Tone Control
Peak Detect and Limiter
Disabled
Disabled
Disabled
Disabled
-
-
Data Selection
Data Input (PCM) to DAC
-
-
Channel Mix
DAC
PCMA = L; PCMB = R
-
-
Charge Pump Frequency
(64xFs)/7
-
-
Table 2. Hardware Mode Feature Summary
