CS43L21
+1.8V or +2.5V
1 µF
VQ
FILT+
0.1 µF
1 µF
DGND
VL
0.1 µF
+1.8V, 2.5 V
or +3.3V
I²S/LJ
MCLKDIV2
RESET
LRCK
AGND
DEM
MCLK
SCLK
0.1 µF
VA_HP
VD
SDIN
CS43L21
1 µF
+1.8V or +2.5V
AOUTB
AOUTA
470
470
C
C
R
ext
R
ext
See Note 2
For best response to Fs/2 :
470
4
470
ext
ext
R
Fs
R
C
This circuitry is intended for applications where the CS 43L21 connects directly to an unbalanced output of the device . For
internal routing applications please see the DAC Analog Output Characteristics section for loading limitations .
Note 2 :
Digital Audio
Processor
0.1 µF
VA
Headphone Out
Left & Right
Line Level Out
Left & Right
Speaker Driver
FLYP
FLYN
VSS_HP
GND_HP
51.1
0.022 µF
1 µF
See Note 1
Note 1:
Series resistance in the path of the power supplies (typically
used for added filtering) must be avoided. Any voltage drop
on VA_HP will directly impact the negative charge pump
supply (VSS_HP) and result in clipping on the audio output .
1 µF
1 µF
**
**
* *Use low ESR ceramic capacitors.
See Note 3
Note 3:
Pull-up to VL (47 k
for Master Mode. Pull-
down to DGND for Slave Mode.
47 k
TSTO/M/S
VL or DGND
k
Figure 2. Typical Connection Diagram (Hardware Mode)
