J2

HPOUTA FLT/NOFLT

Selects filtered or unfiltered output

for HPOUTA

*2 - 4, *1 - 3

Unfiltered output selected for HPOUTA.

4 - 6, 3 - 5

RC filtered output selected for HPOUTA.

J3

HPOUTB FLT/NOFLT

Selects filtered or unfiltered output

for HPOUTB

*2 - 4, *1 - 3

Unfiltered output selected for HPOUTB.

4 - 6, 3 - 5

RC filtered output selected for HPOUTB.

J34

Board Power

Selects source of Board Power

1 - 2

Board powered from external +5 V source con-
nected to TP9/TP10.

*2 - 3

Board powered from USB.

J16

Tri-state I/O

Tri-states FGPA I/O

SHUNTED

FGPA I/O pins are tri-stated.

*OPEN

FGPA I/O pins in normal operation.

*Default factory settings

Table 3. Jumper Settings
