CS4299-BQ
30
4.18
AC Mode Control Register (Index 5Eh)
DDM
DAC Direct Mode. This bit controls the source to the line and alternate line output drivers. When
‘set’, the L/R DACs directly drive the line and alternate line outputs by bypassing the audio mix-
er. When ‘clear’, the audio mixer is the source for the line and alternate line outputs.
AMAP
Audio Slot Mapping. This read/write bit controls whether the CS4299-BQ responds to the Co-
dec ID based slot mapping as outlined in the AC ’97 2.1 specification. The bit is shadowed in
the Extended Audio ID Register (Index 28h). Refer to Table 8 for the slot mapping configura-
tions.
SM[1:0]
Slot Map. The SM[1:0] bits define the Slot Mapping for the CS4299-BQ when the AMAP bit is
‘cleared’. Refer to Table 8 for the slot mapping configurations.
Default
0080h
4.19
Misc. Crystal Control Register (Index 60h)
LOSM
Loss of SYNC Mute Enable. The LOSM bit controls the loss of SYNC mute function. If this bit
is ‘set’, the CS4299-BQ will mute all analog outputs for the duration of loss of SYNC. If this
bit is ‘cleared’, the mixer will continue to function normally during loss of SYNC. The
CS4299-BQ expects to sample SYNC ‘high’ for 16 consecutive BIT_CLK periods and then
‘low’ for 240 consecutive BIT_CLK periods, otherwise loss of SYNC becomes true.
Default
0023h
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
0
0
0
0
0
0
0
DDM
AMAP
0
SM1
SM0
0
0
0
0
Slot
Assignment
Mode
Codec ID
Slot Map
AMAP
Slot Assignments
ID1
ID0 SM1 SM0
DAC,
SPDIF
ADC
L
R
L
R
AMAP Mode 0
0
0
X
X
1
3
4
3
4
AMAP Mode 1
0
1
X
X
1
3
4
3
4
AMAP Mode 2
1
0
X
X
1
7
8
7
8
AMAP Mode 3
1
1
X
X
1
6
9
6
9
Slot Map Mode 0
X
X
0
0
0
3
4
3
4
Slot Map Mode 1
X
X
0
1
0
5
6
5
6
Slot Map Mode 2
X
X
1
0
0
7
8
7
8
Slot Map Mode 3
X
X
1
1
0
9
10
9
10
Table 8. Slot Mapping
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
0
0
0
0
Reserved
0
0
Reserved
0
Reserved
LOSM
30
DS319-BQPP2
CS4299-BQ
