CS4265
6.18
Transmitter Control 2 - Address 12h
6.18.1
Transmitter Digital Interface Format (Bits 7:6)
Function:
The required relationship between LRCK, SCLK and SDIN for the transmitter is defined by the Transmitter
Digital Interface Format and the options are detailed in
6.18.2
Transmitter Output Driver Control (Bit 5)
Function:
When this bit is cleared, the transmitter output pin driver will be in the normal operational mode. When
set, the transmitter output pin driver will drive to a constant 0 V.
6.18.3
Transmitter Mute Control (Bit 4)
Function:
When this bit is cleared, the transmitter data will be in the normal operational mode. When set, the trans-
mitter will output all zero data.
6.18.4
Transmitted Validity Bit Control (Bit 3)
Function:
This bit sets the transmitted Validity bit level.
When this bit is cleared, valid linear PCM audio data is indicated. When this bit is set, invalid or non-linear
PCM audio data is indicated.
6.18.5
Transmitter Mono/Stereo Operation Control (Bit 2)
Function:
When this bit is cleared, the transmitter will operate in stereo mode. When set, the transmitter will operate
in Mono Mode with one input channel’s data output in both A and B subframes (see
Status (C) Bit Management” on page 53
) and the CS data defined by the MMTCS bit (see Section
).
6.18.6
Mono Mode CS Data Source (Bit 1)
Function:
When this bit is cleared, the transmitter will transmit the channel A CS data in the A subframe and the
channel B CS data in the B subframe.
When this bit is set, the transmitter will transmit the CS data defined for the channel selected by the
MMTLR bit in both the A and B subframes.
7
6
5
4
3
2
1
0
Tx_DIF1
Tx_DIF0
TxOff
TxMute
V
MMT
MMTCS
MMTLR
Tx_DIF1
Tx_DIF0
Description
Format
Figure
0
0
Left Justified, up to 24-bit data (default)
0
0
1
I²S, up to 24-bit data
1
1
0
Right-Justified, 16-bit Data
2
1
1
Right-Justified, 24-bit Data
3
Table 18. Transmitter Digital Interface Formats
