14 DS657F3
CS4265
11. Valid when the line-level inputs are selected.
DC Accuracy
Gain Error - -  10 %
Gain Drift -

100 - ppm/°C
Line-Level Input Characteristics
Full-scale Input Voltage 0.51*VA 0.57*VA 0.63*VA V
pp
Input Impedance (Note 11) 6.12 6.8 7.48 k
Maximum Interchannel Input Impedance
Mismatch
- 5 - %
Line-Level and Microphone-Level Inputs
Parameter Symbol
Commercial Grade
Unit Min Typ Max
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Programmable Gain Characteristics
Gain Step Size - 0.5 - dB
Absolute Gain Step Error - - 0.4 dB
