CS4220 CS4221
6 DS284PP3
DIGITAL CHARACTERISTICS
(T
A
= 25° C; VA, VD = 4.75V - 5.25V)
ABSOLUTE MAXIMUM RATINGS
(AGND, DGND = 0 V, all voltages with respect to 0 V.)
RECOMMENDED OPERATING CONDITIONS
(AGND, DGND = 0 V, all voltages with respect to 0 V.)
Notes: 8. Any pin except supplies. Transient currents of up to 100 mA on the analog input pins will not cause SCR
latch-up.
9. The maximum over or under voltage is limited by the input current.
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Parameter Symbol Min Max Unit
High-level Input Voltage VL = 5V
VL = 3V
V
IH
V
IH
2.8
2.0 VL + 0.3
VL + 0.3 V
V
Low-level Input Voltage V
IL
-0.3 0.8 V
High-level Output Voltage at I
O
= -2.0 mA V
OH
VL - 1.0 - V
Low-level Output Voltage at I
O
= 2.0 mA V
OL
- 0.5 V
Input Leakage Current Digital Inputs - 10 µA
Output Leakage Current High Impedance Digital Outputs - 10 µA
Parameter Symbol Min Max Unit
Power Supplies Digital
Analog
VD
VA
-0.3
-0.3 6.0
6.0 V
Input Current (Note 8) - ±10 mA
Analog Input Voltage (Note 9) -0.7 VA + 0.7 V
Digital Input Voltage (Note 9) -0.7 VD + 0.7 V
Ambient Temperature Power Applied -55 +125 °C
Storage Temperature -65 +150 °C
Parameter Symbol Min Typ Max Unit
Power Supplies Digital
Analog
Digital
| VA - VD |
VD
VA
VL
4.75
4.75
2.7
-
5.0
5.0
5.0
-
5.25
5.25
5.25
0.4
V
Ambient Operating Temperature T
A
-10 25 70 °C
