CRD5378
48 DS639RD2
4. BILL OF MATERIALS
CIRRUS LOGIC CRD5378_Rev_A1.PL
BILL OF MATERIAL
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
1
004-00068-Z1
A
CAP 4.7uF ±10% 10V NPb TANT CASE A
2
C1 C59
KEMET
T491A475K010AS
2
001-04345-Z1
A
CAP 0.1uF ±10% 50V X7R NPb 0805
7
C2 C11 C12 C31 C48 C60 C78
KEMET
C0805C104K5RAC
3
001-01997-Z1
A
CAP 0.01uF ±10% 25V X7R NPb 0603
4
C3 C6 C7 C14
KEMET
C0603C103K3RAC
4
004-00092-Z1
A
CAP 68uF ±10% 10V TANT NPb CASE C
5
C4 C5 C20 C51 C53
KEMET
T491C686K010AT
5
001-02194-Z1
A
CAP 0.1uF ±10% 25V X7R NPb 0603
21
C13 C15 C16 C24 C25 C26 C30 C33 C36 C44 C45 C49 C61 C62 C65 C66 C67 C68 C70 C71 C72
KEMET
C0603C104K3RAC
6
001-06603-Z1
A
CAP 0.01uF ±5% 25V C0G NPb 1206
5
C37 C38 C39 C40 C41
KEMET
C1206C103J3GAC
7
000-00008-Z1
A
NO POP CAP NPb 0805
0
C46 C50
NO POP
NP-CAP-0805
DO NOT POPULATE
8
070-00010-Z1
A
DIODE SCHTKY BAR 30V 0.2A NPb SOT23
1
D
1
PHILIPS SEMICONDUCTORS
BAT54
9
070-00024-Z1
A
DIODE SWT 70V 215mA NPb SOT-23
2
D7 D8
ON SEMICONDUCTOR
BAV99LT1G
10
070-00055-Z1
A
DIODE ARRAY 5V (TVS) ESD NPb SOT143
1
D
9
LITTELFUSE
SP0503BAHTG
11
115-00221-Z1
A
HDR 8X2 ML .050" ST GLD NPb SM
4
J1 J2 J5 J6
SAMTEC
FTS-108-01-L-DV
12
110-00263-Z1
A
CON USB RCPT RA 5POS MINI-B NPb TH
1
J
3
MOLEX
54819-0519
13
115-00054-Z1
A
HDR 3x1 ML .1"CTR S GLD NPb
1
J
4
SAMTEC
TSW-103-26-G-S
14
115-00011-Z1
A
HDR 10x2 ML .1" 062BD ST GLD NPb TH
1
J26
SAMTEC
TSW-110-07-G-D
15
115-00013-Z1
A
HDR 2x2 ML .1"CTR .062BD S GLD NPb
1
J57
SAMTEC
TSW-102-07-G-D
16
115-00003-Z1
A
HDR 5x2 ML .1"CTR S GLD NPb
1
J60
SAMTEC
TSW-105-07-G-D
17
080-00004-Z1
A
WIRE JUMPER 2P 0.1" BRASS NPb TH
0
JP1 JP2
COMPONENTS CORPORATION
TP-101-10
NO POP
18
304-00004-Z1
A
SPCR STANDOFF 4-40 THR NPb .500"L
4
MH1 MH2 MH5 MH6
KEYSTONE
2203
REQUIRES SCREW 4-40X5X16" PH STEEL, 300-00001-01
19
020-00788-Z1
A
RES 10 OHM 1/10W ±1% NPb 0603 FILM
9
R1 R11 R13 R14 R16 R25 R26 R60 R68
DALE
CRCW060310R0FKEA
20
000-00002-Z1
A
NO POP RES NPb 0603
0
R2 R3 R4 R8 R9 R15 R17 R22 R23 R32 R33 R39 R40 R41 R42 R45 R49 R50 R51 R55 R56 R61 R63 R69 R70
NO POP
NP-RES-0603
DO NOT POPULATE
21
020-01095-Z1
A
RES 4.99k OHM 1/10W ±1% NPb 0603
1
R
5
DALE
CRCW06034K99FKEA
22
020-01128-Z1
A
RES 9.53k OHM 1/10W ±1% NPb 0603
1
R
6
DALE
CRCW06039K53FKEA
23
020-01130-Z1
A
RES 10k OHM 1/10W ±1% NPb 0603 FILM
1
R
7
DALE
CRCW060310K0FKEA
24
020-00673-Z1
A
RES 0 OHM 1/10W ±5% NPb 0603 FILM
16
R10 R24 R34 R36 R43 R44 R46 R47 R48 R52 R53 R54 R57 R59 R62 R71
DALE
CRCW0603000Z0EA
ECO554
25
021-01391-Z1
A
RES 18M OHM 1/8W ±5% NPb 0805
2
R31 R38
PANASONIC
ERJ6GEYK186V
26
020-01048-Z1
A
RES 2k OHM 1/10W ±1% NPb 0603 FILM
2
R35 R37
DALE
CRCW06032K00FKEA
27
020-01016-Z1
A
RES 1k OHM 1/10W ±1% NPb 0603 FILM
4
R64 R65 R66 R67
DALE
CRCW06031K00FKEA
28
020-06253-Z1
A
RES 412k OHM 1/4W ±1% NPb 1206
1
R147
DALE
CRCW1206412KFKEA
29
060-00195-Z1
A
IC LOW V DUL SPST ANA SW NPb MSP8
2
U1 U2
VISHAY
DG2003DQ-T1-E3
30
060-00163-Z1
A
IC LNR 300mA LSE LDO REG NPb MSOP8
1
U
3
LINEAR TECH
LT1962EMS8-2.5#PBF
31
061-00062-Z1
A
IC LOG SGL D-FF CLR PREST NPb SSOP8
5
U4 U9 U10 U15 U16
TEXAS INSTRUMENTS
SN74LVC2G74DCTRE4
32
060-00063-Z1
A
IC LNR V REG200mA NEGADJ NPbSOT23-5
1
U
5
LINEAR TECH
LT1964ES5-BYP#PBF
33
060-00162-Z1
A
IC 3.3V U LW PWR RS485 XCVR NPSOIC8
4
U12 U13 U17 U18
LINEAR TECH
LTC1480IS8#PBF
34
060-00236-Z1
A
IC LNR PRC VRF 2.5V TC10 NPbSO8-150
1
U14
LINEAR TECH
LT1019AIS8-2.5#PBF
35
065-00229-Z2
G
IC CRUS HI-Z DIDO AMP NPb SSOP24
1
U19
CIRRUS LOGIC
CS3302A-ISZ/G
ECO554
36
065-00196-Z1
A
IC CRUS TEST DAC NPb SSOP28
1
U20
CIRRUS LOGIC
CS5373A-ISZ/A
37
065-00130-Z1
A
IC CRUS 1CH DIG FLTR NPb SSOP28
1
U22
CIRRUS LOGIC
CS5378-ISZ/A
38
062-00079-Z1
A
IC PGM USB 16kB FLAS MCU NPb LQFP32
1
U28
SILICON LABORATORIES INC
C8051F320-GQ
39
102-00017-Z2
A
OSC 32.768MHz 90ppm 3.3V VCL NPb SM
1
Y
1
CITIZEN
CSX750VBEL32.768M-UT
40
070-00053-Z1
A
DIODE ZEN TR SUP 5V 600W PK NPb SM
2
Z1 Z2
ON SEMICONDUCTOR
1SMB5.0AT3G
41
603-00237-Z1
A
ASSY DWG PWA CRD5378-Z NPb
REF
CIRRUS LOGIC
603-00237-Z1
42
240-00237-Z1
A
PCB CRD5378-Z NPb
1
CIRRUS LOGIC
240-00237-Z1
43
600-00237-Z1
A1
SCHEM CRD5378-Z NPb
REF
CIRRUS LOGIC
600-00237-Z1
ECO554
44
300-00025-Z1
A
SCREW 4-40X5/16" PH MACH SS NPb
4
XMH1 XMH2 XMH5 XMH6
BUILDING FASTENERS
PMSSS 440 0031 PH
45
020-06288-Z1
A
RES 680 OHM 1/10W ±1% NPb 0603 FILM
4
R27 R28 R29 R30
DALE
CRCW0603680RFKEA
ECO554
