CRD5378
42 DS639RD2
3.4.2 Statistics
The Statistics control displays calculated statistics for the selected analysis channel. For multichannel
data captures, only one channel of calculated statistics are displayed at a time and is selected using the
Statistics channel control.
Errors that affect statistical calculations will cause the Plot Error control to appear. Information about er-
rors on specific channels can be accessed by enabling the plot of the channel using the Plot Enable con-
trol and then accessing the Plot Error controls.
3.4.3 Cursor
The Cursor control is used to identify a point on the graph using the mouse and then display its plot values.
When any point within the plot area of the graph is clicked, the Cursor will snap to the closest plotted point
and the plot values for that point display below the graph.
Control Description
Time Domain
Max Maximum code of collected data set.
Min Minimum code of collected data set.
Histogram
Max Maximum code of collected data set.
Min Minimum code of collected data set.
Mean Mean of collected data set.
Std Dev Standard Deviation of collected data set.
Variance Variance of collected data set.
Signal FFT
S/N Signal to Noise of calculated FFT.
S/PN Signal to Peak Noise of calculated FFT.
S/D Signal to Distortion of calculated FFT.
S/N+D Signal to Noise plus Distortion of calculated FFT.
# of bins Number of Bins covering the Nyquist frequency.
Noise FFT
S/N Signal to Noise of calculated FFT.
S/PN Signal to Peak Noise of calculated FFT.
Spot Noise dB Spot Noise in dB/
√Hz of calculated FFT.
Spot Noise nV Spot Noise in nV/
√Hz of calculated FFT.
# of bins Number of Bins covering the Nyquist frequency.
