RADWAG Scales of WPT series - Manual (Page 82)

- 82 -
WPT
3/6HR2
WPT
6/15HR2
WPT
15/30HR3
WPT
30/60HR3
WPT
60/150HR3
Scale type:
WPT
3/6HR2/K
WPT
6/15HR2/K
WPT
15/30HR3/K
WPT
30/60HR3/K
WPT
60/150HR3/K
Max capacity 3/6kg 6/15kg 15/30kg 30/60kg 60/150kg
Min capacity 20/40g 40/100g 100/200g 200/400g 400/1000g
Readability 1/2g 2/5g 5/10g 10/20g 20/50g
Verification division 1/2g 2/5g 5/10g 10/20g 20/50g
Tare range -6kg -15kg -30kg -60kg -150kg
Platform size 250 × 300mm 410 × 410mm
OIML class III
Work temperature -10°C to +40°C
Storage temperature -25° to +70°C
Interfaces RS 232
Ingress protection rating IP 68 - construction, IP 68 – tensometer, IP 66/67 - indicator
Power supply 220÷240VAC 50Hz (optional 110÷120VAC 60Hz) and SLA 6V/3,4Ah
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Net / Gross weight 9/10,3kg 15,5/17,3kg
Package dimensions 580x320x360mm 670x510x330mm
WPT
30/60HR4
WPT
60/150HR4
WPT
30/60HR5
WPT
60/150HR5
Scale type:
WPT
30/60HR4/K
WPT
60/150HR4/K
WPT
30/60HR5/K
WPT
60/150HR5/K
Max capacity 30/60kg 60/150kg 30/60kg 60/150kg
Min capacity 200/400g 400/1000g 200/400g 400/1000g
Readability 10/20g 20/50g 10/20g 20/50g
Verification division 10/20g 20/50g 10/20g 20/50g
Tare range -60kg -150kg -60kg -150kg
Platform size 500 x 500mm 600 x 600mm
OIML class III
Work temperature -10°C to +40°C
Storage temperature -25° to +70°C
Interfaces RS 232
Ingress protection rating IP 68 - construction, IP 68 – tensometer, IP 66/67 - indicator
Power supply 220÷240VAC 50Hz (optional 110÷120VAC 60Hz) and SLA 6V/3,4Ah
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Net / Gross weight 23,5 / 25,8kg 29,5 / 31,8kg
Package dimensions 840x600x400mm 840x700x400mm
