NEXT>>>ADVANCE www.nextadvance.com
SP500 series OEM Programmable Syringe Pump
NE500 series manual 29 Revision 101101
8.5.3 Configuration and Setup Commands
New settings for any of the following commands will be stored in the non-volatile memory.
SET PUMP NETWORK ADDRESS
* ADR [
Set/query pump network address
This is a special system command that will be accepted by the pump regardless of its current
address. Once set, the pump will only respond to commands with the set address.
ENABLE SAFE COMMUNICATIONS MODE
SAF [ ]
Set/query Safe communications mode setting.
=> [ [ ] ]
Valid range: 0 to 255.
if = 0 then Basic communication mode is set, disabling Safe mode,
If > 0 then Safe communications mode is enabled. After the reception of this
command, valid communications must be received every seconds.
ALARM SETUP
AL [ ]
Set/query alarm setup mode. Set alarm enables or disables alarm buzzer mode.
POWER FAIL SETUP
PF [ ]
Set/query Power Failure mode. Set Power Failure enables or disables Power Failure mode.
TTL I/O OPERATIONAL TRIGGER SETUP
TRG [ ]
Set/Query TTL I/O Operational Trigger input configuration.
TTL I/O Operational Trigger is set to .
=> FT = Foot switch trigger (falling edge)
LE = TTL Level trigger (rising and falling edge)
ST = Start only trigger (falling edge)
TTL I/O DIRECTIONAL CONTROL INPUT SETUP
DIN [ 0 | 1 ]
Set/query directional control input setup
Settings => 0 = Falling edge: Infuse, Rising edge Withdraw
Use this setting with the CBL-TTL-1, reciprocating pump cable, to create a 2
pump continuous infusion system
1 = Falling edge: Withdraw, Rising edge Infuse
Use this setting with the CBL-TTL-1, reciprocating pump cable, to create a 2
pump dual pumping system
