Page 6

85106-90

Declaration of Conformity

R. M. Young Company

2801 Aero Park Drive

Traverse City, MI 49686 USA

Model 85106

The undersigned hereby declares on behalf of R. M.

Young Company that the above-referenced product, to

which this declaration relates, is in conformity with the

provisions of:

Council Directive 2004/108/EC (December 15, 2004)

on Electromagnetic Compatibility

David Poinsett

R&D Manager

Serial ASCII and ASCII POLLED formats report a STATUS

CODE where non-zero values indicate insufficient samples or

measurement error. SET14n determines how the STATUS CODE

is handled in the voltage output.

1 = None (ignore STATUS CODE)

2 = Set Vouts to 0V when STATUS is non-zero

3 = Set Vouts to 5V full scale when STATUS is non-zero

6.4.15 CALnn FORCE VOUT

This command forces both voltage outputs channel to either 0mV

or 5000 mV. This may be used to calibrate or check the operation

of external data acquisition devices. 00=0 mV, 01=5000 mV

6.4.16 XX, RPT, and ??

XX

Returns the sensor to OPERATE MODE.

RPT

Reports the latest parameter settings.

??

Prints a list of commands.

7.0 EXAMPLE SETTINGS

Use the 2DSETUP program for the following suggested settings.

Not all possible setting combinations are shown.

7.1 VOLTAGE OUTPUT ONLY, MINIMUM POWER

Serial Output Format: ASCII

RS-232

Disabled

RS-485

Disabled

Voltage Output:

Enabled

Output Delay:

122

Sample Count:

0

7.2 RS-232 ONLY, CONT ASCII OUTPUT, MINIMUM POWER

Serial Output Format: ASCII

RS-232

Enabled

RS-485

Disabled

Voltage Output:

Disabled

Output Delay:

122

Sample Count:

0

7.3 RS-232 ONLY, POLLED ASCII OUTPUT, MINIMUM POWER

Serial Output Format: ASCII POLLED

RS-232

Enabled

RS-485

Disabled

Voltage Output:

Disabled

Sample Count:

0

7.4 RS-232 ONLY, POLLED ASCII OUTPUT

Serial Output Format: ASCII POLLED

RS-232

Enabled

RS-485

Disabled

Voltage Output:

Disabled

Sample Count:

Set to 0 if polling frequently. Set to

highest anticipated wind speed (m/s)

up to 31 if polling infrequently. Average

current consumption is a function of

polling rate and sample count.

7.5 SDI-12 CONTINUOUS

Serial Output Format: SDI-12 CONT

Output Delay:

0

Sample Count:

0

7.6 SDI-12 STANDBY

Serial Output Format: SDI-12 STANDBY

Output Delay:

0

Damping Factor:

0

Sample Count:

Set to 0 if polling frequently. Set to

highest anticipated wind speed (m/s)

up to 31 if polling infrequently. Average

current consumption is a function of

polling rate and sample count.

8.0 WARRANTY

This product is warranted to be free of defects in materials and

construction for a period of 12 months from date of initial purchase.

Liability is limited to repair or replacement of defective item. A

copy of the warranty policy may be obtained from R. M. Young

Company.

9.0 CE COMPLIANCE

This product has been tested and shown to comply with European

CE requirements for the EMC Directive. Please note that shielded

cable must be used.
