North, Appendix a: wiring connections – Young Ultrasonic Anemometer Marine Model Model 85106 User Manual
Page 16
Page 13
85106-90
MODEL 85106 ULTRASONIC ANEMOMETER
+V
(WIND FROM NORTH)
+U
(WIND FROM EAST)
(U-V)
CARTESIAN
POLAR
(SPEED, WIND DIRECTION)
EXAMPLE:
WIND AT 45°
E - 90°
N - 0°
W - 270°
S - 180°
FRONT VIEW
MOUNTING:
STANDARD 1" NPT PIPE
1.32" DIA (Ø34.0MM)
ORIENTATION RING
WHEN PROPERLY
ALIGNED, JUNCTION
BOX FACES SOUTH
NORTH
TOP VIEW
407 [16.0]
INSTALL VERTICALLY AS SHOWN TO AVOID
MOISTURE DAMAGE TO CIRCUITRY.
MOUNTING
DEPTH
114 [4.5]
170 [6.7]
APPENDIX A: WIRING CONNECTIONS
