85106-90

The sensor wind speed threshold is preset to 0.25 m/s

(0.6 mph). Wind below this level is displayed as zero.

The wind direction display will show the last value that

appeared when wind speed was above threshold.

3.3 Verify sensor response by using a small fan or gently

blowing through the measuring section. Move the fan to

create wind from several different directions and confirm

changes on the Wind Tracker display. Small fans and

gentle blowing create irregular flow patterns. This test is

for general checkout only.

If the Marine Wind Tracker display continuously shows "Ser Err"

then it is not receiving data from the sensor. Remove power and

check all wiring connections. If the problem cannot be corrected,

contact your YOUNG representative.

If the sensor is NOT USED with a YOUNG Marine Wind Tracker,

an alternative output must be used to check operation. For voltage

output, a voltmeter may be used as an indicator. For other serial

formats, use the wiring diagrams and appropriate parameter

settings as a guide. See sections 5.0 and 6.0 of this manual.

IMPORTANT: NMEA, the default serial output format, transmits

ASCII data. Using a communication program such as

HyperTerminal will allow for monitoring the serial output.

4.0 INSTALLATION

4.1 PLACEMENT

Proper instrument placement is important. Eddies from buildings,

trees, or other structures can influence measurements. For

most applications, locate the sensor well above or upwind of

obstructions. As a general rule, air flow around a structure is

disturbed to 2 times the height of the structure upwind, 6 times the

structure downwind, and up to 2 times the height of the structure

above ground.

4.2 MOUNTING AND ALIGNMENT

The sensor mounts to standard 1-inch (IPS) pipe with an outside

diameter of 1.34 inches (34 mm).

Generally, the sensor is aligned to north. In this orientation, the

sensor junction box faces south (180 degrees). The transducers

may be used as sighting aids. See diagram APPENDIX B.

4.2.1 Place orientation ring over pipe with guide pin up.

4.2.2 Place sensor mounting post over pipe.

4.2.3 Using the transducers as a sighting aid, align the sensor

with a feature on the horizon that represents the proper

orientation. After alignment, tighten the mounting post

band clamp to secure the position. DO NOT OVER-

TIGHTEN.

4.2.4 Slide the orientation ring up so its guide pin is fully

engaged in the sensor mounting post notch. Tighten the

orientation ring band clamp to secure its position. DO

NOT OVER- TIGHTEN.

If the sensor needs to be removed later, leave the orientation ring

on the pipe to preserve sensor alignment.

4.3 CONNECTIONS

With long cable lengths, resistance in the power supply wires

reduces the available voltage at the sensor. Power at the sensor

must be in the range of 9 to 16 VDC when the sensor is operating.

See WIRING DIAGRAMS in APPENDIX A.

5.0 OPERATION

5.1 WITH YOUNG MARINE WIND TRACKER DISPLAY

The default serial output format is NMEA which is compatible with

the Young Model 06206 Marine Wind Tracker display. The Marine

Wind Tracker receives measurements in the form of ASCII data

via an RS-485 serial connection. The Wind Tracker automatically

converts the data to wind values which appear on the display. Set

the Wind Tracker input to 'SER'. See the Marine Wind Tracker

manual for display options.

5.2 VOLTAGE OUTPUTS

When the default NMEA format is used, analog voltage outputs are

active. These may be connected to a data logger or other device

such as the YOUNG Model 26700 Programmable Translator. See

VOLTAGE OUTPUTS in APPENDIX A for connection details and

calibration values.

Voltage outputs may be enabled with any serial output format

except SDI-12 even if the serial output connection itself is disabled.

Polar speed and direction, which is the default, or Cartesian (UV)

voltage output format may be selected. See section 6.4.13 and

APPENDIX B for additional details. The voltage output may also be

set to signal the STATUS CODE. The default setting causes VOUT

to ignore the STATUS CODE. See sections 5.3.2 and 6.4.14 for

additional details.

When cable length between voltage output terminals and data

acquisition system exceeds 3m (10 ft.), the voltage outputs should

be measured differentially.

5.3 SERIAL OUTPUT FORMATS

A variety of serial output formats are available. From the factory, it

is programmed for operation with the Young Marine Wind Tracker

display (NMEA format). Other serial formats are selected using a

PC and the Windows 2DSETUP program (2Dsetup.exe) provided.

The following sections discuss format options available. Each

command is discussed in detail in section 6.0.

5.3.1 RMYT

RMYT is a 6-byte binary data format sent at 9600 baud using the

RS -485 OUTPUT ONLY connections. This format is used with the

YOUNG Model 06201 Wind Tracker.

If RMYT default parameters are used (no other parameters

altered), the maximum number of internal samples are always

used, measurements and outputs run continuously, voltage outputs

are enabled, and both RS-232 and RS-485 connections are

enabled. The average current consumption is about 150 mA, not

including heater power.

5.3.2 ASCII

ASCII output provides continuous wind measurement data in text

format. Between each measurement cycle, the sensor goes into a

low power mode. There are a number of parameters related to the

ASCII serial output format which may be altered.

Please note that

the default values are recommended for most applications.

Careful analysis of the sensor's application should be done prior

to making changes due to the interaction of parameters such as

OUTPUT DELAY and SAMPLE COUNT. See section 6.0.

ASCII output appears either in POLAR or CARTESIAN (UV)

format. With POLAR format, the wind speed threshold and wind

speed units are selected. With CARTESIAN format, the threshold

is ignored and wind speed units are always meters per second

(m/s).
