Page 5

85004-90

parameters are automatically changed. This may change the baud

rate from its current setting. See section 6.4.2 for details on which

parameters are altered.

Although new parameter values are stored immediately when the

command is issued, they do not take effect until the sensor enters

OPERATE MODE.

COMMAND

DESCRIPTION

SET01nn Set OUTPUT MODE

01

Enable voltage output

02

Enable RS-232

04

Enable RS-485 full duplex

08

Enable RS-485 half duplex

16

Enable RS-485 output only

SET02nn Set OUTPUT FORMAT

01

RMYT (default)

02

ASCII

03

ASCII POLLED

04

NMEA

05

SDI-12 CONTINUOUS

06

SDI-12 STANDBY

SET03nn Set BAUD RATE

12

1200

48

4800

96

9600

38

38400

SET04nn Set ASCII WS UNITS

01

MPH

02

KNOTS

03

KMPH

04

M/S

SET05c

ASCII character sensor address (0-9, A-Z, a-z)

SET06nnn

Wind speed threshold for polar output (cm/s)

SET07nnnnn Wind speed scale (nnnnn/10000)

SET08nnnnn Direction offset (±nnnnn degrees x 10)

SET09nn

Damping factor

SET10nnn

Output delay (0-999 x 8.192 milliseconds)

SET11nn

Direction VOUT (36=0-360, 54=0-540 degrees)

SET12nn

Sample count (00=auto or 03-31)

SET13nn

ASCII and Vout format (00=polar, 01=UV)

SET14nn

Vout Status Code (1=none, 2=0V, 3=FS)

CALnn

Force Vout (00=0V, 01=5V)

XX

Go to OPERATE MODE

RPT

Report parameter settings

??

Help list

6.4 COMMAND DETAILS

6.4.1 SET01nn SET OUTPUT MODE

This parameter independently enables and disables voltage output,

RS-232, and RS-485 connections. For example, to enable voltage

output, RS-232, and RS-485 full duplex, add the code for each one:

01 + 02 + 04 = 07,

SET0107. To enable only RS-232: SET0102. If

RS-485 is used, choose only one RS-485 option (04, 08, or 16). See

section 6.3 for codes.

To reduce power consumption, enable only those outputs that are

needed. When SDI-12 format is selected with the

SET02nn com-

mand, voltage output, RS-232, and RS-485 connections are disabled

and SDI-12 is enabled.

6.4.2 SET02nn SET OUTPUT FORMAT

This parameter determines the serial output data format. See section

5.0 for operational details. When selecting some formats, parameters

are automatically changed as listed below:

FORMAT

ADDITIONAL

CODE

PARAMETERS CHANGED

01 RMYT

BAUD = 9600

OUTPUT MODE = 07

THRESHOLD = 25 cm/s

OUTPUT DELAY = 01

SAMPLE COUNT = 31

02 ASCII

03 ASCII POLLED

None

04 NMEA

BAUD = 4800

OUTPUT MODE = 19

THRESHOLD = 25 cm/s

OUTPUT DELAY = 122

SAMPLE COUNT = 31

05 SDI-12 CONT

06 SDI-12 STANDBY

1200 baud

Both SDI-12 settings automatically disable voltage output, RS-232,

and RS-485 connections. With either POLLED ASCII or SDI-12

STANDBY, set the Damping Factor to 0 (see section 6.4.9).

6.4.3 SET03nn SET BAUD RATE

All RS-232 and RS-485 communication use the baud rate set with

this parameter. Power consumption is affected by this setting since

it influences communication duration.

6.4.4 SET04nn SET ASCII WIND SPEED UNITS

Sets wind speed units for ASCII, ASCII POLLED, and SDI-12 polar

outputs only.

6.4.5 SET05c SET POLL ADDRESS CHARACTER

Sets the sensor address for ASCII POLLED and SDI-12 formats. The

default is '0' (ASCII 48).

6.4.6 SET06nn SET WIND SPEED THRESHOLD

Sets the wind speed threshold for polar outputs (wind speed and

direction) to suppress scattered wind direction indications in calm

air. Winds below the threshold are reported as zero, wind direction

is held at last value when wind speed was above threshold. Set

threshold in centimeters per second (m/s x 100). The default setting

is 25 cm/s (0.25 m/s, 0.56 mph).

6.4.7 SET07nnnnn SET WIND SPEED MULTIPLIER

All wind speed measurements are multiplied by this parameter. The

default value is 10000 for a multiplier of 1.0000. This may be used to

individually calibrate each sensor for improved accuracy.

6.4.8 SET08nnnnn SET WIND DIRECTION OFFSET

Use this parameter to add or subtract a wind direction offset. Value

is degrees x 10 and may be positive or negative. Wind direction is

always re-scaled to a 0-360 range after offset is applied. The default

value is 00000.
