19 WIKA operating instructions temperature switch model TSD-30
GB
11613025.02 12/2011 GB/D/F/E
6. Commissioning, operation
Menu (programming and factory setting)
Display mode
▲ ▼
Long pressing of the "MENU" key
Programming mode Factory setting:
▲ ▼
SP1 / FH1 Value Min: MBA + 0.5 %, Max: MBE MBE
▲ ▼
RP1 / FL1 Value Min: MBA, Max: SP1 - 0.5 % MBE -10 %
▲ ▼
SP2 / FH2 Value Min: MBA + 0.5 %, Max: MBE MBE
▲ ▼
RP2 / FL2 Value Min: MBA, Max: SP2 - 0.5 % MBE -10%
▲ ▼
EF RES Yes / No Reset to factory setting
▲ ▼
DS1 Value 0 ... 50 s 0 s
▲ ▼
DR1 Value 0 ... 50 s 0 s
▲ ▼
DS2 Value 0 ... 50 s 0 s
▲ ▼
DR2 Value 0 ... 50 s 0 s
▲ ▼
OU1 PARA HNO, HNC, FNO, FNC HNO
▲ ▼
OU2 PARA HNO, HNC, FNO, FNC HNO
▲ ▼
UNIT Unit °C, °F Order-related
▲ ▼
SETR 4 mA / 0V Value MBA - 25 % of span MBA
▲ ▼
20 mA / 10V Value MBE + 25 % of span MBE
OFS Yes / No Offset setting 3 % of span 0 s
▲ ▼
ACT, HIGH, LOW, OFF, SP1/FH1, RP1/FL1,
SP2/FH2, RP2/FL2
ACT DISM PARA
▲ ▼
DISR Yes / No Rotate display indicator by 180°
▲ ▼
RHL Yes / No Reset HIGH, LOW
▲ ▼
PAS Value Password without
▲ ▼
TAG Value Measuring point number without
▲ ▼
Legend:
MBA = Start of measuring range
MBE = End of measuring range
END END
▼ ▼ ▼ ▼
Display mode
