10 WIKA operating instructions pressure transmitter, model MHC-1
14035467.01 08/2012 GB/D/F/E
GB
3. Specifications
3.4 Reference conditions (per IEC 61298-1)
Temperature
15 ... 25 °C
Atmospheric pressure
860 ... 1,060 mbar
Humidity
45 ... 75 % relative
Power supply
DC 24 V
Nominal position
Calibrated in vertical mounting position with pressure connection facing downwards.
3.5 Accuracy data
Accuracy at reference conditions
Including non-linearity, hysteresis, zero offset and end value deviation (corresponds to measured error
per IEC 61298-2).
Accuracy
Standard ≤ ±1 % of span
Option ≤ ±0.5 % of span
Measuring rate
maximum 1,000 Hz
Non-linearity (per IEC 61298-2)
≤ ±0.2 % of span BFSL
