9 Supplement
9 .1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
-
Housing plastic PBT, Alu die-casting, 316L
-
Inspection window in housing cover for
indicating and adjustment module Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Weight 0.35 kg (0.772 lbs)
Ambient conditions
Ambient temperature -15 … +70 °C (+5 … +158 °F)
Storage and transport temperature -40 … +80 °C (-40 … +176 °F)
Electromechanical data
Cable gland 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm), 1 x
blind stopper M20 x 1.5 or 1 x closing cap ½ NPT,
1 x blind stopper ½ NPT
Spring-loaded terminals for wire cross-sec-
tion up to 2.5 mm² (AWG 14)
Indicating and adjustment module
Voltage supply and data transmission through the sensor via gold-coated sliding contacts
(I²C-Bus) in the external indicating and adjustment
unit
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
-
unassembled IP 20
-
mounted in the external indicating and
adjustment unit without cover IP 40
Materials
-
Housing ABS
-
Inspection window Polyester foil
Adjustment circuit
Connection to IPT-1* sensors
Data transmission digital (I²C-Bus)
Configuration connection cable 4-wire, screened
Cable length max. 25 m
