Basic setting level
1 ▶ Basic adjustment
Display
Diagnostics
Service
Info
1.1 Application
Level ▼
1.1 Unit
Unit of measurement
bar ▼
Temperature unit
°C ▼
1.2 Position correction
Offset
DP =
-0.0035 bar
0.0000 bar
1.3 Min. adjustment
000 .0 %
=
0 .0000 bar
0 .0000 bar
1.4 Max. adjustment
100 .00 %
=
0 .5000 bar
0.0000 bar
1.5 Damping
1 s
1.6 Linearisation curve
▶ linear
Cylindrical tank
Spherical tank
User programmable
1.7 Sensor-TAG
Sensor
Display
2 Basic adjustment
▶ Display
Diagnostics
Service
Info
2.1 Displayed value
Differential pressure ▼
2.1 Displayed value
AI-Out
2.4 Lighting
Switched off ▼
Diagnostics
3 Basic adjustment
Display
▶ Diagnostics
Service
Info
3.1 Pointer
p-min.: -5.8 mbar
p-max.: 167.5 mbar
T-min.: -12.5 °C
T-max.: +85.5 °C
3.2 Sensor status
OK
3.3 Trend curve
Start trend curve?
3.4 Total sum counter
0.0000 10
00
gal
Modify settings?
3.5 Part sum counter
0.0000 10
00
gal
Modify settings?
Differential pressure transmitter DPT10 - metal measuring diaphragm • Foundation Fieldbus 55
6 Adjustment with the indicating and adjustment module
