9 WIKA operating instructions pressure transmitter model A-10
11218720.10 01/2012 GB/D/F/E
GB
CE, Communauté Européenne
Instruments bearing this mark comply with the relevant European directives.
Voltage DC
3. Specifications
3.1 Measuring ranges
Relative pressure
bar Measuring range 0 ... 1 0 ... 1.6 0 ... 2.5 0 ... 4 0 ... 6
Overpressure limit 2 3.2 5 8 2
Measuring range 0 ... 10 0 ... 16 0 ... 25 0 ... 40 0 ... 60
Overpressure limit 20 32 50 80 120
Measuring range 0 ... 100 0 ... 160 0 ... 250 0 ... 400 0 ... 600
Overpressure limit 200 320 500 800 1,200
psi Measuring range 0 ... 15 0 ... 25 0 ... 30 0 ... 50 0 ... 100
Overpressure limit 30 60 60 100 200
Measuring range 0 ... 160 0 ... 200 0 ... 300 0 ... 500 0 ... 1,000
Overpressure limit 290 400 600 1,000 1,740
Measuring range 0 ... 1,500 0 ... 2,000 0 ... 3,000 0 ... 5,000 0 ... 10,000
Overpressure limit 2,900 4,000 6,000 10,000 17,400
2. Safety / 3. Specifications
