13 WIKA operating instructions pressure transmitter model A-10
11218720.10 01/2012 GB/D/F/E
GB
3.7 Electrical connections
Specifications
Designation Ingress
protection
Wire
cross-section
Cable Ø Cable
material
Angular connector DIN 175301-803 A
■ with mating connector IP 65 up to max. 1.5 mm 2 6 ... 8 mm -
■ with solid laid cable IP 65 3 x 0.75 mm 2 6 mm PUR
Angular connector DIN 175301-803 C
■ with mating connector IP 65 up to max. 0.75 mm 2 4.5 ... 6 mm -
■ with solid laid cable IP 65 4 x 0.75 mm 2 5.9 mm PUR
3. Specifications
3.5 Reference conditions (per IEC 61298-1)
Temperature:
15 ... 25 °C
Atmospheric pressure: 860 ... 1,060 mbar
Humidity: 45 ... 75 % relative
Power supply: DC 24 V
Mounting position: as required
Service life
10 million load cycles
Temperatures
Permissible temperature range
Standard Option
Ambient 0 ... +80 °C -30 ... +100 °C
Medium 0 ... +80 °C -30 ... +100 °C
Storage -20 ... +80 °C -30 ... +100 °C
