IQ SERIES T1 + DSX-1 NETWORK INTERFACE MODULE (NIM)

P/N 1202803L1

For more detailed documentation, visit us online at

www.adtran.com

Quick Start Guide, 61202803L1-13A, March 2004

Technical Support 1-888-4ADTRAN (1-888-423-8726)

Copyright

© 2004 ADTRAN, All Rights Reserved

T1 N

ETWORK

(RJ-48C) C

ONNECTION

P

INOUT

Pin

Name

Description

1

R1

Receive data from the network

2

T1

Receive data from the network

3

UNUSED

4

R

Transmit data toward the network

5

T

Transmit data toward the network

6-8

UNUSED

DSX-1 I

NTERFACE

(RJ-48C) P

INOUT

Pin

Name

Description

1

R1

Transmit data toward the DTE

2

T1

Transmit data toward the DTE

3

UNUSED

4

R

Receive data from the DTE

5

T

Receive data from the DTE

6-8

UNUSED
