Technical Specifications
14
9 Technical Specifications
Technical specifications of the TP-185 are shown in Table 6 .
Table 6: Technical Specifications
1
INPUTS:
of the TP-185
8 UXGA on 15-pin HD connectors (VGA through WUXGA)
8 unbalanced stereo audio 3.5mm mini jacks
OUTPUTS: 8 TP on RJ-45 connectors
RESOLUTION: Up to WUXGA (1920 x 1200)
RANGE: Up to 100m (328ft)
MAX. OUTPUT LEVEL: VIDEO: 1.6Vpp AUDIO: 2.3Vpp
CONTROLS: RS-232 3 pin terminal block
RS-485 3 pin terminal block
SERIAL BAUD RATE: Up to 19200kbps
SERIAL MODE: Full-duplex
BANDWIDTH: AUDIO: 20Hz to 20kHz @0.5dB
S/N RATIO: AUDIO: <-80dB
TOTAL GAIN: Audio: 0dB
COUPLING: Audio: AC
AUDIO THD + NOISE: Audio: <0.03%
POWER CONSUMPTION: 100-240V AC, 16VA
OPERATING
TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE
TEMPERATURE:
–45° to +72°C (–49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 48.26cm x 19.1cm x 1U (19" x 7.52" x 1U) W, D, H
WEIGHT: 3.8kg (8.4lbs) approx
ACCESSORIES: Power cord, Windows
®
-based control software, rack “ears”
10 Default Communication Parameters
Table 7
Table 7: TP-185 Communication Parameters
lists the TP-185 default communication parameters.
RS-232
Protocol 2000
Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: None
Command Format: HEX
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81
1 Specifications are subject to change without notice
