TP-133/TP-134 - Technical Specifications 13
13
7 Technical Specifications
TP-133 TP-134
INPUTS: Video: 1 Computer graphics on a
15-pin HD connector
Audio: 1 Unbalanced stereo audio
on a 3.5mm mini jack
1 Balanced stereo audio on a
5-pin terminal block
Data: 1 RS-232 bidirectional on a
9-pin D-sub connector
Communication: 1 LINE IN on an
RJ-45 connector
OUTPUTS: Video Loop: 1 Computer graphics
on a 15-pin HD connector
Audio Loop: 1 Balanced stereo
audio on a 5-pin terminal block, 1
Unbalanced stereo audio on a
3.5mm mini jack
Communication: 1 RJ-45 LINE
OUT on an RJ-45 connector
Video: 1 Computer graphics on a
15-pin HD connector
Audio: 1 Balanced stereo audio
on a 5-pin terminal block,
1 Unbalanced stereo audio on a
3.5mm mini jack
Data: 1 RS-232 bidirectional on a
9-pin D-sub connector
CONTROLS: Skew/Equalization
VIDEO RESOLUTION: Up to WUXGA
MAX. OUTPUT LEVEL: Video: 1.1V
Audio: 2.2V
AUDIO:
BANDWIDTH: Audio: 20–20kHz @-3dB
S/N RATIO:
Audio: 84dB/unweighted
COUPLING: AC
TND+N: Audio: 0.02% unweighted
RS-232: BAUD RATE: Up to 115200bps
MODE: Full-duplex
POWER SOURCE: 5.3V DC 450mA 5.3V DC 760mA
TRANSMISSION
DISTANCE:
Up to 200m (656ft)
OPERATING
TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE
TEMPERATURE:
–45° to +72°C (–49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 19.05cm x 8.63cm x 2.44cm (7.5" x 3.4" x 0.96") W, D, H
WEIGHT: 0.33kg (0.73lbs.) approx. each
ACCESSORIES: Power supply, AD-GF/GF 15−pin
HD (F/F) Gender Changer
Power supply
OPTIONS: RK-T2B 19” rack adapter, Kramer BC-DGKat623
