8 TP-133/TP-134 - Connecting the TP-133/TP-134
To connect the TP-133 and the TP-134 to create a TP transmitter and
receiver system as illustrated in
Figure 3
1. On the TP-133, connect:
:
 A computer graphics video source (for example, the graphics card on a
laptop) to the PC IN 15-pin HD connector (M)
 An unbalanced, stereo audio source (for example, the audio source on
the computer graphics station) to the AUDIO IN 3.5mm mini jack
 The RS-232 device, for example, PC or controller with an RS-232
interface to the RS-232 9-pin D-sub connector (F)
 The balanced, stereo audio source (for example, a DAT-Player) to the
BAL AUDIO IN 5-pin terminal block
 If needed, connect a computer monitor and audio
amplifier/loudspeakers to the looping VGA/audio outputs (not shown in
Figure 3
2. On the TP-134, connect the:
)
 BAL AUDIO OUT 5-pin terminal block to the balanced, stereo audio
acceptor (for example, an amplifier)
 AUDIO OUT 3.5mm mini jack to the unbalanced, stereo audio
acceptor (for example, an AV display system)
 PC VIDEO OUT 15-pin HD (F) connector to the video acceptor (for
example, an AV display system)
 RS-232 9-pin D-sub connector (M) to the controlled device with an
RS-232 interface
3. Using STP cabling, connect the LINE OUT RJ-45 connector on the TP-133
to the LINE IN RJ-45 connector on the TP-134 (see Section 5.2
4. Connect the power adapters to the power sockets on the TP-133 and
TP-134, and connect the adapters to the mains electricity (not shown in
).
Figure 3 ).
