Overview
2
3 Overview
This section describes:
• A summary of the PT-110 XGA Line Transmitter, see section
3.1
• A summary of the WP-110 XGA Line Transmitter, see section
3.2
• A summary of the PT-120 XGA Line Receiver, see section
3.3
• A summary of the TP-120 XGA Line Receiver, see section
3.4
• The power connect feature, see section
3.5
• Using shielded twisted pair (STP) / unshielded twisted pair (UTP), see
section 3.6
• Recommendations for achieving the best performance, see section
3.7
3.1 PT-110 XGA Line Transmitter
Using an XGA Line Transmitter—the PT-110 or WP-110—with the
PT-120 or TP-120 constitutes a VGA/XGA-to-Twisted Pair Transmitter
and Receiver.
The Kramer Pico TOOLS PT-110 is an XGA line transmitter that receives
an XGA signal and transmits it over a CAT 5 cable to the PT-120 or
TP-120 receiver. In particular, the PT-110:
• Has a resolution of up to UXGA
• Can use the simplest UTP CAT 5 cables, and performs even better with
higher quality cables
• Has the Power Connect feature
• Is 12V DC fed
3.2 WP-110 XGA Line Transmitter
The Kramer Wall Plate WP-110 is an XGA line transmitter—available in
three versions: one for the USA, one for Belgium and Germany, and one for
the UK and most of Europe
1
—that receives an XGA signal and transmits it
over a CAT 5 cable to the PT-120 or TP-120 receiver. In particular, the
WP-110:
• Has a resolution of up to UXGA
• Can use the simplest UTP CAT 5 cables, however, it benefits from
better quality cables
• Has the power connect feature
• Is powered via a standard 12V DC feed
1 Excluding Belgium and Germany
