Technical Specifications
12
6 Technical Specifications
Table 6 lists the technical specifications:
Table 6: Technical Specifications
1
of the PT-110 / WP-110 / PT-120 / TP-120
PT-110 WP-110 PT-120 TP-120
INPUTS: 1 VGA / UXGA on a
15-pin HD connector
1 VGA / UXGA on a
15-pin HD connector
1 RJ-45 LINE IN
connector
1 RJ-45 LINE IN
connector
OUTPUTS: 1 RJ-45 LINE
OUTPUT connector 1 RJ-45 LINE OUT
connector
1 VGA / UXGA on a
15-pin HD connector
1 VGA / UXGA on a
15-pin HD connector
MAX. OUTPUT
LEVEL:
1.5Vpp 1.4Vpp
RESOLUTION: Up to UXGA
DIFF. GAIN
2
: 2.9% (worst case)
DIFF. PHASE
2
0.3 Deg (worst case)
K-FACTOR 2 : <0.05%
S/N RATIO
2
: 69dB (worst case)
CONTROLS: –7.7dB to +3.1dB,
130m level,
0dB to +25dB
EQ. @ 50MHz
–7.5dB to +4.4dB,
130m level, 0dB to
+33dBm 130m,
EQ. @ 50MHz
COUPLING: AC AC DC AC
POWER SOURCE: 12V DC 60mA 12V DC 60mA 12V DC 175mA 12V DC 160mA
DIMENSIONS: 6cm x 6.5cm x 2.5cm
(2.36" x 2.56" x 1")
W, D, H
USA: 6.9cm x 3.8cm x
11.4cm (2.72" x 1.5" x 4.5")
W, D, H
6cm x 6.5cm x 2.5cm
(2.36" x 2.56" x 1")
W, D, H
12cm x 7.5cm x 2.5cm
(4.7" x 0.98" x 2.95")
W, D, H
Belgium and Germany:
8cm x 3.8cm x 8cm
(3.15" x 1.5" x 3.15")
W, D, H
UK and most of Europe 3 :
8.6cm x 3.8cm x 8.6cm
(3.39" x 1.5" x 3.39")
W, D, H
WEIGHT: 0.14kg (0.31lbs)
approx.
0.14kg (0.31lbs) approx. 0.14kg (0.31lbs)
approx. 0.3kg (0.66lbs)
approx.
ACCESSORIES: Power supply
OPTIONS: 19-inch rack adapters
1 Specifications are subject to change without notice
2 For the transmitter/receiver pair
3 Excluding Belgium and Germany
