SWM-1 - Installing the SWM-1 7
Dual Insert:
Connect the ball interface to the
adapter interface using an
M6x12mm screw, and then connect
them to the two holes on the
loudspeaker rear panel, using screw
types A, B or C (see Section 4.2 ).
Keyhole Insert:
Insert the M5x12mm screw through
the hole in the ball interface and
tighten with the keyhole insert. Insert
the screw head into the keyhole and
push it upwards.
No Inserts Available:
Connect the ball interface to the
adapter interface using an
M6x12mm screw, and then use the
two M4.2x19mm wood screws (see
Section 4.2 ) to connect them to the
loudspeaker rear panel.
