Kramer Electronics SWM-1 - Manual (Page 7)

SWM-1 - Defining the SWM-1 Loudspeaker Wall Mount Device 5
4.2 The Loudspeaker Interface Kit
The loudspeaker interface screws are used to attach the wall mount to the
loudspeaker. Use the screws in the kit that fit the hole threading on the
loudspeakers.
# Part per Unit
A M5x12mm Screw (2)
B M6x12mm Screw (2)
C UNC 1/4”x5/8” Screw (2)
D M4.2x19mm (No.8x3/4”) Wood Screw (2)
E Keyhole insert (1)
4.3 The Wall Fixing Kit
Use the wall fixing screws and wall plugs to fix the wall mount with the
loudspeaker to the wall.
# Parts per Unit
A1 M4.8x32mm Wood Screw (2)
A2 No6 Wall Plug, for part A1 (2)
