Technical Specifications
15
7.4 Installing the Web Applet
Follow these steps to install the Web Applet 1
1. Connect RC-8IR to your PC through computer networking.
:
2. Start the RC Configuration Software and connect to the RC device (see
the RC Configuration and Installation Guide 2
3. In the Device menu select Upgrade Applet option and browse to MC.dat
file included in the package.
).
4. Wait until uploading is completed and the success message appears.
Click OK.
8 Technical Specifications
Table 6 defines the technical specifications:
Table 6: Technical Specifications
3
PORTS:
of the RC-8IR Universal Room Controller
2 RS-232 on terminal block connectors
1 RS-485 on a terminal block connector
1 ETHERNET RJ-45 port
OUTPUTS: 2 relays on terminal block connectors (36V AC or DC, 2A, 60VAC maximum on
non-inductive load)
2 IR emitters on terminal block connectors
POWER SOURCE: 12V DC, 155mA
DIMENSIONS:
11.4cm x 3.7cm x 6.9cm (4.49" x 1.45" x 2.72", W, D, H)
WEIGHT: 0.3kg (0.67lbs) approx
ACCESSORIES: Kramer 3.5mm to IR Emitter Control Cable (C-A35/IRE-10), power supply, two
extra M3x5 screws, Java based control software (internal), Windows®-based
Kramer control software
OPTIONS: Kramer 3.5mm to IR Emitter Control Cable (C-A35/IRE-10), 15 meter and 20 meter
IR emitter extension cables
1 This section is applicable only to firmware version 26.0 and higher and requires RC Configuration Software version
1.26.0.38 and higher
2 On our Web site at
http://www.kramerelectronics.com
3 Specifications are subject to change without notice
