Technical Specifications
31
Table 10: Technical Specifications for 88 Series
VS-88A VS-88V SD-7588A SD-7588V
INPUTS: 8 balanced stereo audio, +4
dBm/33k on detachable terminal
blocks
8 composite video, 1Vpp/75 on
BNCs, looping Analog sync inputs
1Vpp/75 on BNCs
8 AES/EBU digital audio, 110
on detachable terminal blocks,
transformer coupled
8 x SMPTE - 259M serial video, 75
on BNCs; looping Analog sync
inputs on BNCs
OUTPUTS: 8 balanced audio stereo, +4
dBm/50 Vpp max) on detachable
terminal blocks
8 composite video, 1Vpp/75 on
BNCs
8 reclocked AES/EBU digital
audio, 110 on detachable
terminal blocks, transformer
coupled
8 reclocked SMPTE-259M outputs,
75 on BNCs
SAMPLING: 32, 44.1, 48, 96 kHz sampling
frequencies
RESOLUTION: Up to 24-bit, automatic according
to input resolution
10-bit or 8-bit, automatic according
to input resolution
STANDARDS: AES/EBU, IEC 958, S/PDIF and
EIAJ CP340/1201
4fsc PAL, 4fsc NTSC, 4:2:2
(525/625), and 360Mb/s wide
screen (525/625)
VIDEO BANDWIDTH: 200 MHz 3dB
VIDEO CROSSTALK: < -50 dB @ 5 MHz
VIDEO S/N: >74 dB
DIFF. GAIN: <0.05%
DIFF. PHASE: <0.03 Deg
K-FACTOR: < 0.05%
AUDIO BANDWIDTH: > 40 kHz; 0.3db
AUDIO CROSSTALK: < - 90 dB
AUDIO S/N: > 90 dB unweighted (1Vpp)
AUDIO THD: < 0.02% (1Vpp, 1kHz)
MAXIMAL AUDIO 20 dBm
EQUALIZATION: Automatic up to 200mV eye
pattern
Automatic for up to 300m for 270
Mb/s using Belden 8281 cable
DISPLAY: Current switcher status on eight 7-segment bright LEDs Current switcher status on eight 7-segment bright LEDs. Signal presence
for each channel on front panel LEDs
CONTROLS: 22 front-panel touch switches, RS-232 and RS-485 control interface
