Your Matrix Switchers
9
4.3 Your SD-7588A 8x8 Digital Audio Matrix Switcher
The SD-7588A is a high performance multi-standard 8x8 digital audio matrix
switcher that is adjustment-free, cable-equalized and reclocking. In addition,
the SD-7588A:
Provides automatic equalization for losses on 110 twisted pair cable
Reclocks each output to provide eight low-jitter digital outputs
Supports AES/EBU, IEC 958, S/PDIF and EIAJ CP340/1201 professional and
consumer formats with sampling frequencies up to 96kHz
Comes with all inputs and outputs transformer coupled, supporting 110
impedance twisted pair cable on detachable terminal block connectors
Is controllable via the front panel buttons as well as the built-in RS-232 and
RS-485 interfaces
Includes 15 preset memory locations for quickly and easily accessing the most
frequently used configurations
May be used with the RC-8000, an optional remote controller (see section 0)
Functions as a standalone unit as well as part of a Kramer multi-signal switcher
system 1
Figure 3 and Table 3 define the SD-7588A:
1 Which includes digital and analog video, digital and analog audio and RS-422 control switchers. When integrated in a
system, it switches together with the video during the vertical interval, thus supporting true IN SYSTEM mode
