Connecting Your Matrix Switchers
20
6.2 Connecting a Standalone Unit
To connect a standalone unit:
Connect the power supply
Connect the audio and/or video input and output cables
Connect the video reference input for
VS-88V and/or SD-7588V
Set dipswitch # 1 OFF and dipswitches # 2, 3, 4, 5 and 6 ON (see section 6.1)
The IN SYSTEM button is non responsive
6.3 Connecting Several Units with/without the Remote Controller
To connect several units with or without the remote controller:
Connect the power supply
Connect the audio and/or video input and output cables
Connect the video reference input for
VS-88V or SD-7588V
In a system with more than one video switcher (either VS-88V or SD-7588V),
connect all video switchers to the video reference by looping between the sync
BNC connectors
Set the dipswitches for the different MACHINE # (1 to 8) for each machine
and set dipswitch # 5 OFF and dipswitch # 6 ON
Connect all the 4 terminals to the RS-485 interface connectors
Operate the front panel controls of any switcher
Figure 7 illustrates a typical system connection:
