Your Matrix Switchers
11
Table 3: SD-7588A 8x8 Digital Audio Matrix Switcher Features
# Feature Function
1 Power Switch Illuminated switch supplying power to the unit
2 ALL Button
(ALL= All Outputs) Pressing ALL before pressing an INPUT button, connects that input to all
outputs 1
3 OFF Button
(OFF= All Inputs) Pressing OFF after pressing an OUTPUT button disconnects that output from
the inputs. To turn off the connections, press the ALL button and then the OFF
button
4 OUT Select the output to which the input is switched SELECT
Buttons
IN Select the input to switch to the output
5 STO Button Pressing STO (STORE) followed by an output button stores the current setting
(refer to section 8.2.1) 2
6 RCL Button Pressing the RCL (Recall) button and the corresponding OUT key recalls a
setup. Press the RCL button again to implement the new status (refer to
section 8.2.2)
7 IN SYSTEM Button Pressing IN SYSTEM twice 3 , switches between the Standalone mode (in
which the switcher implements any action independently from the others) and
the In System mode (in which all switchers implement the same action
simultaneously)
8 TAKE Button
(TAKE = CONFIRM) Pressing TAKE toggles the mode between the CONFIRM mode 4 and the AT
ONCE mode (user confirmation per action is unnecessary)
9 OUTPUT labels Identifies a connection between the output and the input shown below it
INPUT Status Display Displays the selected input switched to the output (marked above each input)
10 INPUT STATUS LEDs Illuminate when the input signal is presented on a corresponding line and
complies with the AES/EBU standard
11 INPUTS Connectors Audio inputs
12 OUTPUTS Connectors Audio outputs
13 MACHINE # Dipswitches For setup of the machine number (refer to section 6.1)
14 RS-485 Connector RS-485 detachable terminal block port. Pins # 1 to # 3 are for RS 485 and pin
# 4 is for vertical sync distribution 5
15 Power Connector with
Fuse
AC connector enabling power supply to the unit
16 RS-232 OUT 9-pin D-sub
Connector
Connects to the RS-232 IN 9-pin D-sub port of the next unit in the daisy-chain
connection 6
17 RS-232 IN 9-pin D-sub
Connector
Connects to PC or Remote Controller 7
1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs
2 For example, press STO and then the Output button # 3 to store in Setup # 3
3 After pressing IN SYSTEM once, it blinks
4 When in Confirm mode, the TAKE button illuminates
5 The 88 Series RS-485 connector has 4 pins, and the Remote Controller RS-485 connector has just 3 pins
6 If the unit is the final unit in the daisy-chain connection, no termination is required
7 If the unit is not the first unit in the line, connects to the RS-232 OUT 9-pin D-sub port of the previous unit in the line
