7.3.1 Storing an Input/Output Configuration
To store the current status in memory, do the following:
1. Press the STO button.
The STO button blinks.
2. Press one of the OUT SELECT buttons (this will be the setup # in which
the current status is stored). The number of the selected setup # blinks on
the display and the STO button continues blinking.
3. Press the STO button again.
The STO button stops blinking.
7.3.2 Recalling an Input/Output Configuration
To recall an input/output configuration, do the following:
1. Press the RCL button.
The RCL button blinks.
2. Press the appropriate OUT SELECT button (the button # corresponding
to the setup #). That setup configuration will blink in the 7-segment
Display.
The memory recalls the stored data from that reference.
After pressing the RCL button again, the settings will take effect.
8 Technical Specifications
Table 4 includes the technical specifications:
Table 4: Technical Specifications
1
of the VS-88HD 8x8 SD/HD-SDI Matrix Switcher
INPUTS: 8 SDI SMPTE-259M, 292M, 344M serial video, 75 ohms on BNC connectors
1 GENLOCK 75 / Hi-Z on a BNC connector
OUTPUTS: 8 equalized SMPTE-259M, 292M, 344M outputs 75 ohms on BNC
connectors
1 Looped GENLOCK 75 / Hi-Z on a BNC connector
MAX. OUTPUT LEVEL: 800mVpp /75 ohms
DATA RATE: Up to 1.485Gbps
CONTROLS: Front-panel, RS-232; and RS-485
POWER SOURCE: Universal, 90-240VAC, 50/60Hz 18VA
DIMENSIONS: 19 inch (W), 7 inch (D), 1U (H) rack mountable
WEIGHT: 2.6 kg. (5.7 lbs.) approx.
ACCESSORIES: Power cord, Null-modem Adapter
1 Specifications are subject to change without notice
